Description
TP-Link SG2016P | Omada 16-Port Gigabit Smart Switch with 8-Port PoE+
The TP-Link SG2016P is a powerful 16-port Gigabit smart switch featuring 8 PoE+ ports, delivering up to 120W total PoE budget. Perfect for powering IP cameras, wireless access points, VoIP phones, and other PoE devices in small to medium business environments.
Key Features
High-Performance PoE+ Networking
- 16× Gigabit RJ45 ports with 8× 802.3at/af-compliant PoE+ ports
- 120W total PoE budget with up to 30W per port output
- 32 Gbps switching capacity and 23.81 Mpps packet forwarding rate
Omada SDN Integration
- Centralised cloud management via web or Omada app
- Zero-Touch Provisioning with Omada Cloud-Based Controller
- Automatic device discovery and batch configuration
Enterprise-Grade Features
- VLAN support with up to 4K VLAN groups
- Static routing with 32 IPv4/IPv6 routes
- Access Control Lists (ACL) with up to 230 entries
- QoS with 802.1p CoS/DSCP priority and 8 queues
Flexible Management Options
- Web-based GUI management
- Command Line Interface (CLI) via telnet
- SNMPv1/v2c/v3 support
- RMON monitoring capabilities
Silent & Durable Design
- Fanless design for completely silent operation
- Durable metal casing for reliability
- Desktop or wall-mount installation options
- Compact size: 286 × 111.7 × 25.4mm
Technical Specifications
Hardware
| Specification | Details |
|---|---|
| Ports | 16× 10/100/1000 Mbps RJ45 (Ports 1-8 PoE+) |
| PoE Standard | 802.3af/at compliant |
| PoE Budget | 120W total |
| Switching Capacity | 32 Gbps |
| Packet Forwarding | 23.81 Mpps |
| MAC Address Table | 8K entries |
| Jumbo Frame | 9 KB |
| Dimensions | 286 × 111.7 × 25.4mm |
Network Features
| Feature | Details |
|---|---|
| VLAN | 4K groups, 802.1Q, MAC VLAN, Voice VLAN |
| Routing | 32 IPv4/IPv6 static routes |
| Multicast | 511 shared groups, IGMP Snooping, MVR |
| QoS | 8 priority queues, SP/WRR scheduling |
| ACL | 230 entries, Time-based, MAC/IP/IPv6 |
Security Features
- IP-MAC-Port Binding
- 802.1X port-based authentication
- DHCP Snooping and ARP Inspection
- DoS Defence
- Port Security (up to 64 MAC per port)
- HTTPS/SSL and SSH management
Management
- Omada Cloud-Based Controller
- Omada Hardware Controller
- Omada Software Controller
- Omada Mobile App
Ideal Applications
CCTV & Security Systems
Power and connect IP cameras with a single cable run, simplifying installation and reducing infrastructure costs.
Wireless Network Deployment
Provide power and connectivity to multiple wireless access points for comprehensive WiFi coverage.
VoIP Phone Systems
Support voice over IP deployments with reliable PoE power and QoS prioritisation for clear call quality.
Small Business Networks
Create a robust, manageable network infrastructure with enterprise features at an affordable price point.
What’s in the Box
- SG2016P Smart Switch
- External Power Adapter (53.5 VDC / 2.43A)
- Installation Guide
- Rubber Feet for Desktop Mounting
Professional Installation Available
Straight Forward Technology provides professional installation and configuration of TP-Link Omada networking equipment across Melbourne and the Mornington Peninsula. Our technicians can:
- Design your network infrastructure
- Install and configure switches for optimal performance
- Set up Omada cloud management
- Integrate with existing CCTV and access control systems
- Provide ongoing managed IT support
Contact us for a quote on supply and installation.
